DD471.3

Ergonomics Ensured By Reliable Height Adjustments

Thanks to their compact design, OKIN’s DD471.3 square lifting columns can be easily integration into a variety of table systems. Their design is also convincing: the lifting columns have a smooth profile surface with no visible openings or indentations. This ensures a sleek appearance that blends in perfectly with the design of the desk.

YOUR COMFORT IS OUR GOAL
The low-play sliding system in the DD471.3 lifting columns allows you to make easy adjustments while maintaining excellent stability. Thanks to a special gear, the lifting columns are very quiet and fast. At a maximum adjustment speed of 35 mm/s, the noise level during operations is less than 48 dB. The two-stage column profiles always move precisely synchronously to ensure that adjustments are reliable and safe.

The drives achieve a pushing force of up to 800 N. This is made possible by the powerful, maintenance-free 24-volt DC motors with two Hall sensors. Another product benefit is the very low installation dimension of 560 mm and the stroke length of 650 mm. The DD471.3 lifting columns can be operated using OKIN’s proven DB02, DB03, SMARTneo and COMPACTeco control units. These can be programmed according to individual customer requirements and feature the ISP intelligent system protection.
